Main stream: 1920x1080@18fps, 1280x720@25fps Sub stream: 640x352@25fps, 320x176@25fps
Main stream: 2560x1920@15fps, 2560x1440@15fps Sub stream: 800x600/800x448@25fps, 640x480/640x352@25fps
Video compression
H.264/H.265
Lens
4.7-94mm 20X optical zoom auto focus lens
View angle
61.4°~3.6°
Night vision
6pcs array infrared LEDs, night vision distance 100m
Audio
Audio compression
G.726/G.711
Audio code rate
8Kbps, 16bit
Audio input
Built-in MIC and speakers, support two way audio
Audio output
Support, can connect speakers
Audio
Audio compression
G.726/G.711
Audio code rate
Rate adaptive
Audio input
Support, can connect the pickup and MIC
Audio output
Support, can connect speakers
Alarm
Motion detecting alarm
Can set 4 independent detection region (1-100 sensitivity can be set)
Alarm linkage
Alarm send pictures to the mailbox, Alarm upload pictures and videos to the FTP server, Alarm record pictures and videos to Micro SD card, Alarm mobile phone message push
Alarm recording
Support Micro SD card and PC client linkage alarm recording
Network
Wireless
IEEE 802.11 b/g/n
Onvif protocol
Support ONVIF 2.4(backward compatible)
Storage
Micro SD card
Support up to 128G micro SD card
Recording mode
Alarm record, timing record,
Video playback
Support APP, IE browser, remote client play and download the video
